FCC-500 RGB LED Controller with Speed Control — 12V/24V, 300W Max, 33 Built-in Modes, Master/Slave | Intellect LED

The FCC-500 is a dual-function RGB controller that runs standalone with 33 built-in lighting modes or drops into slave mode to amplify the signal from a master unit — making it the right choice for both small sign installs and large multi-zone RGB systems.

What sets it apart:

• Accepts 12V or 24V input — works with the power supply you already have on the job
• 300W max output handles demanding RGB runs without a secondary driver
• 33 built-in modes: 25 RGB modes across solid color, flashing, dimming, and multi-color sequences, plus 8 BangBang modes (26–33) for music-reactive or chase effects
• On-board LED display shows the active mode number — no guesswork during setup or commissioning
• Speed control dial lets you tune animation pace per zone independently
• Mode 00 sets the unit as a slave amplifier — daisy-chain unlimited FCC-500s from a single master controller using the included communication cable (extendable as needed)
• All slave units automatically track and amplify the master signal — no individual programming per unit
• Communication ports allow multi-controller expansion for large architectural or signage projects



  Mode	Type	Color / Function
  01–07	RGB	Solid — Red, Green, Blue, Yellow, Pink, Sky Blue, White
  08–14	RGB	Flashing — same 7 colors
  15–21	RGB	Dimming — same 7 colors
  22–25	RGB	Multi-color: 7-color dimming, changing, transition, flashing
  26–33	BangBang	Chase / reactive effects (speed-adjustable)
  00	Slave	Amplifier — mirrors master controller signal via comm port
